SolaX / Inverters
SolaX 8kW Hybrid Inverter
8kW single-phase low-voltage hybrid manufacturer reference with two MPPTs, LCD display, a 40–60V battery connection and IP65 protection. Manufacturer reference: the model below matches the listed capacity and product family, but AJ Solar has not confirmed the exact stocked model suffix, hardware generation or regional configuration. Verify the nameplate and battery compatibility before ordering.
PKR 300,000Ask us for the current price and availability.
Review your solar package →We’ll check equipment compatibility before recommending your complete system.
- Two MPPTs, 32 / 32A maximum input
- 40–60V battery input
- 190 / 190A charge / discharge current
- Backup switchover <6ms
- LCD interface and IP65 protection
- Up to 3 parallel units in on-grid/off-grid operation; configuration requirements apply
Product overview
- Brand
- SolaX
- Model
- X1-Lite-8K-LV · manufacturer reference
- Capacity
- 8 kW
- System type
- Hybrid
- Warranty
- Confirm with AJ Solar
- Availability
- Confirm on WhatsApp
Make it a complete solution.
Add this product to your package and tell us about your property. We can help with load assessment, system design, installation and ongoing support.
Specifications are taken from the manufacturer’s product information for the model shown. Your quotation will confirm the supplied configuration, compatible equipment and local warranty coverage.
Technical specifications
X1-Lite-8K-LV · manufacturer reference · Select a section to view its specifications.
System
- Phase
- Single phase manufacturer reference; phase is unspecified in existing AJ Solar title
- Inverter type
- Hybrid, low-voltage battery manufacturer reference
- Reference model
- X1-Lite-8K-LV
- Series
- X1 Lite LV
PV input
- Maximum recommended PV array power
- 16,000 Wp
- Maximum PV input voltage (2)
- 600 V
- Rated PV input voltage
- 360 V
- Operating voltage range
- 50–550 V
- Start-up voltage
- 110 V
- MPP trackers / strings per tracker
- 2 / (2 / 2)
- Maximum input current per MPPT
- 32 / 32 A
- Maximum input short-circuit current per MPPT
- 40 / 40 A
AC input and output (on-grid)
- Rated output power
- 8,000 W
- Rated output current
- 34.8 A @ 230 V
- Maximum output apparent power
- 8,800 VA
- Maximum continuous output current
- 38.3 A @ 230 V
- Rated AC voltage
- 220 / 230 / 240 V
- Maximum AC input apparent power
- 12,650 VA
- Maximum AC input current
- 55 A @ 230 V
- Maximum continuous AC passthrough (grid to load)
- 75 A
- Rated AC frequency
- 50 / 60 Hz
- AC frequency range (3)
- 50 ± 5 Hz / 60 ± 5 Hz; country code dependent
- Adjustable power factor range
- Approximately 1; adjustable 0.8 lagging to 0.8 leading
- THDi at rated power
- <3%
Battery
- Battery type
- LFP / lead-acid
- Battery voltage range
- 40–60 V
- Maximum charge / discharge current
- 190 / 190 A
EPS off-grid output (with battery)
- Rated EPS output voltage / frequency
- 230 V, 50 / 60 Hz
- Rated EPS output power
- 8,000 VA
- Peak EPS output power
- 16,000 VA; 2 times rated power for 10 s
- Switchover time
- <6 ms
Efficiency
- Maximum efficiency
- 97.6%
- European efficiency
- 97.0%
Environment limit
- Ingress protection
- IP65
- Operating temperature range
- −25 to +60°C; derating above 45°C
- Maximum operating altitude
- 3,000 m
- Relative humidity
- 4–100% RH, condensing
- Overvoltage category
- Mains III; battery II; PV II
General
- Dimensions (W × H × D)
- 462 × 651 × 280 mm
- Net weight
- 38.5 kg
- Cooling concept
- Smart air cooling
- Communication interfaces
- RS485, CAN, USB, DI/DO
- Display
- LCD
- Topology
- Non-isolated for PV side / high-frequency for battery side
- Certifications
- IEC/EN 62109-1/-2, NRS 097-2-1, IEC 61727, IEC 62116, PEA, MEA, BIS
Protection
- Protections
- Over/under voltage protection, DC isolation protection, DC reverse-polarity protection, grid monitoring, DC injection monitoring, back feed current monitoring, overtemperature protection
- Active anti-islanding method
- Frequency shift
- Surge protection (DC / AC)
- DC Type II / AC Type II
- Arc-fault circuit interrupter (AFCI)
- Optional; feature upgrade qualifier applies
